| Obiettivo FA formato 1.1 " serie Taurus ( 12 MP) |
||
| Modello |
UN-TFA122 8L -12MP |
|
| Lunghezza focale |
12 mm |
|
| Apertura |
F2.8 _ |
|
| Formato immagine |
1,1 ″ |
|
| Montare |
C |
|
| Angolo di campo P x A x V (°) |
|
1,1 '' |
| D |
72,26 ° |
|
| H |
60,46 ° |
|
| V |
47,26 ° |
|
| Distorsione ottica |
≤ 0,5% |
|
| MOD |
0,10 m |
|
| Dimensione |
Φ 51x61.04 |
|
| Flangia BFL |
17 . _ 526mm _ |
|
| Lunghezza focale posteriore _ _ |
9,13 mm |
|
| Operazione |
Iride manuale |
|
| Messa a fuoco manuale |
||
| Lunghezza d'onda di progettazione |
400-900 nm |
|
| Filtro discussione |
M49 *0,75 |
|
Il prossimo :
UN-TFA1620L-12MP
UN-TFA2520L-12MP
Product Features:
· High relative illumination and high contrast
· Low distortion and excellent corner brightness
· High resolution
· Compatible with 1" and 1.1" 12MP camera
Product information: Custom designs are available upon request.
UN-TFA3520L-12MP
Product Features:
· High relative illumination and high contrast
· Low distortion and excellent corner brightness
· High resolution
· Compatible with 1" and 1.1" 12MP camera
Product information: Custom designs are available upon request.
UN-TFA5020L-12MP
Product Features:
· High relative illumination and high contrast
· Low distortion and excellent corner brightness
· High resolution
· Compatible with 1" and 1.1" 12MP camera
Product information: Custom designs are available upon request.
UN-TFA1620L-12MP
UN-TFA7522L-12MP
prismi in vetro di silice fusi e bk7
UN-TFA1624L-12MP
Product Features:
· High relative illumination and high contrast
· Low distortion and excellent corner brightness
· High resolution
· Compatible 1.2" 12MP camera
Product information: Custom designs are available upon request.
UN-GNIR5020L-20MP
Product Features:
· High relative illumination and high contrast
· Low distortion and excellent corner brightness· High resolution
· Compatible with 1" and 1.1" 20MP camera
UN-CLS954.5/V45
Product Features:
· Covering a wide working distance range
· Very low distortion and high resolution· Lockable distance and aperture settings
Product information: Custom designs are available upon request.
UN-GSWIR3514C
