| Obiettivo FA formato 1.1 " serie Taurus ( 12 MP) |
||
| Modello |
UN-TFA 16 2 0L -12MP |
|
| Lunghezza focale |
16 mm |
|
| Apertura |
F2.0 _ |
|
| Formato immagine |
1,1 ″ |
|
| Montare |
C |
|
| Angolo di campo P x A x V (°) |
|
1,1 '' |
| D |
57,62 ° |
|
| H |
47,62 ° |
|
| V |
36,65 ° |
|
| Distorsione ottica |
≤ 0,8% |
|
| MOD |
0,10 m |
|
| Dimensione |
Φ 37 * 62,07 |
|
| Flangia BFL |
17 . _ 526mm _ |
|
| Lunghezza focale posteriore _ _ |
9,81 mm |
|
| Operazione |
Iride manuale |
|
| Messa a fuoco manuale |
||
| Lunghezza d'onda di progettazione |
400-900 nm |
|
| Filtro discussione |
M34 *0,5 |
|
prev :
UN-TFA1228L-12MPIl prossimo :
UN-TFA7522L-12MP
UN-TFA2520L-12MP
Product Features:
· High relative illumination and high contrast
· Low distortion and excellent corner brightness
· High resolution
· Compatible with 1" and 1.1" 12MP camera
Product information: Custom designs are available upon request.
UN-TFA3520L-12MP
Product Features:
· High relative illumination and high contrast
· Low distortion and excellent corner brightness
· High resolution
· Compatible with 1" and 1.1" 12MP camera
Product information: Custom designs are available upon request.
UN-TFA5020L-12MP
Product Features:
· High relative illumination and high contrast
· Low distortion and excellent corner brightness
· High resolution
· Compatible with 1" and 1.1" 12MP camera
Product information: Custom designs are available upon request.
UN-TFA1228L-12MP
UN-TFA7522L-12MP
UN-ALS284K
Product Features:
· Developed for 32mm big frame sensor
· Large Aperture, upto F2.4· Excellent optical performance, uniform imaging of center and edge
Product information: Custom designs are available upon request.
UN-TFA1620L-10MP
UN-ALS184K
Product Features:
· Developed for 30mm big frame sensor
· Large Aperture, up to F2.4· Excellent optical performance, uniform imaging of center and edge
Product information: Custom designs are available upon request.
